Goodman 2.0 Ton split heat pump 14.3 seer single stage GSZB402410
Goodman 2.0 Ton split heat pump 14.3 seer single stage GSZB402410
Couldn't load pickup availability
Model: GSZB402410
Goodman Specifications Sheet Click HERE
PRODUCT: GSZB402410
Specifications:
- Energy-efficient compressor
- Enhanced aluminum fin coil with 5 mm diameter copper tubes in 1.5- to 3.5-ton
- SmartShift® technology to ensure quiet reliable defrost
- Single-speed PSC condenser fan motor
- High and low-pressure switches
- High density compressor sound blanket (1.5-2.0T)
- Factory-installed hard start kits (1.5-2.0T)
- Factory-installed compressor crank case heater
- Factory-installed high-capacity muffler
- Factory installed suction line accumulator
- Factory installed bi-flow filter drier
Warranty:
- Standard warranties apply.
- Standard parts, residential: ALL PARTS - 5 YEARS PARTS
- Standard parts, multi-family: ALL PARTS - 5 YEARS PARTS
- Standard parts, commercial: ALL PARTS - 5 YEARS PARTS
- Registered parts, residential: ALL PARTS - 10 YEARS PARTS
- Registered parts, multi-family: ALL PARTS - 10 YEARS PARTS
- Registered parts, commercial: ALL PARTS - 10 YEARS PARTS
Product Attributes:
Brand: Goodman
Cabinet Features:
Removable grill-style top design compliant with UL 60335-2-40
Increased airflow and enhanced air movement via new, optimized venturi rings
Steel louver coil guard
Heavy-gauge galvanized-steel cabinet
Attractive Architectural Gray powder-paint finish with 500-hour salt-spray approval
Top and side maintenance access
When properly anchored, it meets the 2020 Florida Building Code unit integrity requirements for hurricane-type winds (Anchor bracket kits available.)
Class: Split Heat Pump
Compressor Stages: Single Stage
Compressor Type: Rotary
Cooling Capacity Rated: 22600
Unit Depth: 29
Unit Height: 35.687999999999995
Unit Width: 29
Family Description: Energy-Efficient Split System Heat Pump, 14.3 SEER2 and 7.5 HSPF2, 1-1/2 to 5 Tons
Heating Capacity Rated: 22000
Max. Voltage: 253
Min. Voltage: 197
Model Efficiency: 14.3 SEER2
Power Frequency: 60
Power Phase: 1
Power Voltage: 208/230
Product Benefits: Meets the 2023 M1 Test Standards
Category: Split Heat Pump
Family: GSZB4
Prop65 Label Required: TRUE
Refrigerant: R-410A
Tonnage: 2 tons
Unit Type: Outdoor
Suction Valve Outside Diameter: 3/4
Unit Weight: 160
